Malibu M5-300W-24V 24V 300W Class 2 Multi-Channel 5-in-1 Dimmable Junction Box LED Driver

Malibu M5-300W-24V Multi-Channel 5-in-1 Dimmable Junction Box LED Driver
Engineered for professional and commercial-grade LED lighting systems, the Malibu M5-300W-24V delivers exceptional performance and versatility. This driver offers 5-in-1 dimming compatibility—including TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM—for flicker-free, ultra-smooth dimming in a wide range of applications. Its rugged NEMA 4X-rated metal housing ensures reliable performance in wet, damp, and dry environments, making it ideal for both indoor and outdoor use.
For complete technical details, please refer to the spec sheet.

Key Features

• Multi-Channel Power:

  • Four independent channels delivering 75W each for a total output of 300W.

• 5-in-1 Dimming Compatibility:

  • Supports TRIAC (forward-phase and reverse-phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming technologies.

• Flicker-Free Dimming:

  • Voltage Reduce mode offers dimming from 100% to 0.01%.
  • PWM mode provides dimming from 100% to 0.1%.

• Constant Voltage Output:

  • Maintains a stable output with a voltage tolerance of ±0.5% and load regulation of ±1%.

• Energy Efficiency:

  • Achieves up to 92% efficiency at full load (277VAC) and 90% at 120VAC, minimizing energy costs.

• Durable Construction:

  • Rugged NEMA 4X-rated metal housing ensures reliability in diverse environmental conditions.

• Robust Safety Features:

  • Includes built-in protections against overload, short circuit, and over-temperature conditions.

• Low-Load Capability:

  • Operates efficiently across a load range from 0.01% to 100%, accommodating various LED fixtures.

• Compact Design:

  • Dimensions: 11.38" x 5.2" x 1.67"
  • Weight: 4.63 lbs, ensuring seamless integration into lighting systems.

• Certified Quality & Extended Warranty:

  • Meets UL, cUL, FCC, and RoHS standards.
  • Backed by a 7-year manufacturer warranty.

Product Advantages

• Comprehensive Dimming Compatibility:

  • Integrates seamlessly with multiple dimming systems for versatile lighting solutions.

• Flicker-Free Performance:

  • Ultra-smooth dimming minimizes visual strain and enhances lighting quality.

• Energy Savings:

  • High efficiency and low harmonic distortion (<20%) ensure cost-effective, eco-friendly operation.

• Durable Build & Easy Installation:

  • The innovative clamshell junction box design allows for flexible wiring adjustments, simplifying installation.

Ideal Applications

• LED linear and tape lighting
• Architectural lighting
• Residential and commercial lighting systems
• Moving signs and displays

Specifications

• Input Voltage Range: 120-277VAC
• Efficiency: Up to 92% at full load
• Power Factor: >0.95 at full load
• Output Voltage: 24V DC
• Rated Power: 300W (75W per channel)
• Voltage Tolerance: ±0.5%
• Load Regulation: ±1%
• Safety Certifications: UL, cUL, FCC, RoHS
• Dimensions: 11.38" x 5.2" x 1.67"
• Weight: 4.63 lbs

FAQs

What dimming methods are supported?
This driver supports TRIAC (forward-phase and reverse-phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming technologies.

Can this driver be used outdoors?
Yes, its NEMA 4X-rated metal housing is designed to perform reliably in wet, damp, and dry environments.

What safety features are included?
It features built-in overload, short circuit, and over-temperature protections to ensure secure and safe operation.

What is the dimming range?
The Voltage Reduce mode offers dimming from 100% to 0.01%, while the PWM mode provides a dimming range from 100% to 0.1%, ensuring ultra-deep, flicker-free control.

For complete and detailed specifications, please refer to the spec sheet.
