Malibu

Malibu M5-200W-24V 24V 200W Class 2 Multi-Channel 5-in-1 Dimmable Junction Box LED Driver

Malibu M5-200W-24V 24V 200W Class 2 Multi-Channel 5-in-1 Dimmable Junction Box LED Driver

Regular price $230.00 USD
Regular price Sale price $230.00 USD
Sale Sold out

Engineered for professional and commercial LED lighting systems, the Malibu M5-200W-24V delivers consistent performance and flexible dimming options. With 5-in-1 dimming capabilities—including TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM—it ensures smooth, flicker-free dimming and precise lighting control. Its constant 24V DC output, rated at 200W (8.33A), and energy-efficient design (up to 92% efficiency) deliver reliable performance while reducing energy consumption. Encased in a rugged NEMA 4X-rated metal housing, this driver is built for use in wet, damp, and dry environments, making it ideal for both indoor and outdoor applications. Certified to UL, cUL, FCC, and RoHS standards, it provides safety, durability, and long-term reliability. For complete technical details, please refer to the spec sheet.

Key Features

  • Multi-Channel Power Delivery: Rated at 200W (8.33A at 24V DC) for consistent performance.
  • 5-in-1 Dimming Technology: Supports TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming.
  • Ultra-Smooth, Flicker-Free Dimming:
    • Voltage Reduce mode offers dimming from 100% to 0.01%.
    • PWM mode provides dimming from 100% to 0.1%.
  • Constant Voltage Output: Maintains a stable 24V DC output with ±0.5% regulation.
  • Energy-Efficient Operation: Achieves up to 92% efficiency at full load to reduce energy consumption.
  • Durable Construction: Rugged NEMA 4X-rated metal housing for reliable performance in wet, damp, and dry locations.
  • Advanced Safety Protections: Features built-in safeguards against short-circuit, over-temperature, and overload conditions.
  • Low-Load Compatibility: Performs efficiently even at loads as low as 0.01%.
  • Compact Design: Dimensions of 10" x 5.2" x 1.67" and a weight of 4 lbs make installation easy.
  • Certified Quality: Complies with UL, cUL, FCC, and RoHS standards.
  • Extended Warranty: Backed by a 7-year manufacturer warranty.

Product Advantages

  • Flexible dimming options for universal compatibility with various dimming systems.
  • Flicker-free performance minimizes visual strain and enhances LED longevity.
  • Energy-efficient design ensures cost savings and eco-friendly operation.
  • Robust construction and advanced safety features deliver long-term reliability.
  • Innovative junction box design allows for easy wiring adjustments and installation.

Ideal Applications

  • LED linear and tape lighting
  • Residential and commercial lighting systems
  • Decorative and architectural lighting
  • Moving signs and displays

Specifications

  • Input Voltage Range: 110-277VAC
  • Output Voltage: 24V DC
  • Rated Power: 200W
  • Current: 8.33A
  • Efficiency: Up to 92% at full load
  • Power Factor: >0.95 at full load
  • Dimensions: 10" x 5.2" x 1.67"
  • Weight: 4 lbs
  • Safety Certifications: UL, cUL, FCC, RoHS

FAQs

What dimming methods are supported?
 Supports TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming.

Can this driver be used outdoors?
 Yes, its rugged NEMA 4X-rated metal housing is designed for wet, damp, and dry environments.

What safety features does it include?
 It features built-in protections for short-circuit, over-temperature, and overload conditions.

What is the efficiency rating?
 The driver operates at up to 92% efficiency at full load, ensuring energy savings.
