Malibu Stardust™ M5-180W-12V 12V 180W Class 2 Multi-Channel 5-in-1 Dimmable LED Driver
Engineered for professional LED lighting systems, the Malibu M5-180W-12V delivers exceptional performance and versatility for 12V applications. This Class 2 driver provides a constant 12V DC output at 180W, divided over three independent channels (60W each), ensuring precise control and energy-efficient operation. It supports advanced 5-in-1 dimming technologies—including TRIAC (both forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming—to deliver smooth, flicker-free dimming for a wide range of lighting setups.
Encased in a rugged NEMA 4X-rated metal housing, the M5-180W-12V is built for reliable performance in wet, damp, and dry environments, making it ideal for residential, commercial, and architectural installations. Certified to UL, cUL, FCC, RoHS, and CE standards and backed by a 7-year warranty, it guarantees safe, long-term operation.
Key Features
- Multi-Channel Power Delivery: Three channels, each delivering 60W for a total of 180W.
- 5-in-1 Dimming Technology: Compatible with TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming systems.
-
Flicker-Free Dimming:
- Voltage Reduce mode dims from 100% to 0.01%.
- PWM mode dims from 100% to 0.1%.
- High Energy Efficiency: Operates at up to 92% efficiency at 277VAC and 89% at 120VAC, reducing energy consumption.
- Durable Construction: Rugged NEMA 4X-rated metal housing for reliable use in wet, damp, and dry locations.
- Advanced Safety Protections: Built-in safeguards against overload, short circuit, and over-temperature conditions.
- Compact & Lightweight: Dimensions of 10" x 5.2" x 1.67" and a weight of 4 lbs for easy installation.
- Certified Quality: Meets UL, cUL, FCC, RoHS, and CE standards.
- Extended Warranty: Backed by a 7-year manufacturer warranty.
Product Advantages
- Versatile dimming options provide maximum flexibility in lighting control.
- Low-load capability ensures effective operation even at loads as low as 0.01%.
- High efficiency and low harmonic distortion (<20%) deliver energy savings.
- Rugged design ensures consistent performance in both indoor and outdoor environments.
Ideal Applications
- LED linear and tape lighting
- Residential and commercial lighting systems
- Architectural and decorative lighting
Specifications
- Input Voltage Range: 110-277VAC
- Output Voltage: 12V DC
- Rated Power: 180W (60W per channel)
- Efficiency: 92% at 277VAC; 89% at 120VAC
- Safety Certifications: UL, cUL, FCC, RoHS, CE
- Dimensions: 10" x 5.2" x 1.67"
- Weight: 4 lbs
FAQs
• What dimming methods are supported?
Supports TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming technologies.
• Can this driver be used outdoors?
Yes, its rugged NEMA 4X-rated metal housing is designed for reliable operation in wet, damp, and dry environments.
• What safety features does it include?
It features built-in protections against overload, short circuit, and over-temperature conditions.
• What is the efficiency rating?
The driver operates at up to 92% efficiency at 277VAC and 89% at 120VAC, ensuring energy-efficient performance.
