Malibu Stardust™ M5-150W-24V 24V 150W Class 2 Multi-Channel 5-in-1 Dimmable Junction Box LED Driver
Engineered for 24V LED systems, the Malibu M5-150W-24V delivers reliable and efficient power while supporting advanced dimming technologies. With 5-in-1 dimming capabilities—including TRIAC (forward-phase and reverse-phase), 0-10V, 1-10V, Potentiometer, and 10V PWM—it ensures smooth, flicker-free operation for a wide range of professional lighting applications. Delivering 6.25A of current at 150W, this driver is optimized for precision performance and energy efficiency. Encased in a rugged NEMA 4X-rated metal housing, it is designed for use in wet, damp, and dry environments, making it suitable for both indoor and outdoor installations. Certified to UL, cUL, FCC, RoHS, and CE standards, it guarantees safety, durability, and long-term reliability. For complete technical details, please refer to the spec sheet.
Key Features
- Multi-Channel Power Delivery: Provides 6.25A of current at 150W for consistent and stable performance.
- 5-in-1 Dimming Technology: Supports TRIAC (forward-phase and reverse-phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming systems.
-
Flicker-Free Dimming:
- Voltage Reduce mode offers dimming from 100% to 0.01%.
- PWM mode provides dimming from 100% to 0.1%.
- Energy Efficiency: Operates at up to 90% efficiency at 277VAC and 87% at 120VAC, reducing energy consumption and operating costs.
- Durable Construction: Rugged NEMA 4X-rated metal housing ensures reliable use in wet, damp, and dry locations.
- Advanced Safety Protections: Built-in safeguards against overload, short circuit, and over-temperature conditions ensure secure operation.
- Compact Design: Dimensions of 10" x 5.2" x 1.67" and a weight of 4 lbs allow for easy installation.
- Certified Quality: Complies with UL, cUL, FCC, RoHS, and CE standards.
- Extended Warranty: Backed by a 7-year manufacturer warranty for peace of mind.
Product Advantages
- Versatile dimming options provide maximum flexibility in lighting control.
- Low-load capability: Performs effectively at loads as low as 0.01%.
- Energy savings through high efficiency and low harmonic distortion.
- Rugged build ensures consistent performance across various environments.
Ideal Applications
- LED linear and tape lighting
- Architectural and decorative lighting
- Residential and commercial lighting systems
Specifications
- Input Voltage Range: 110-277VAC
- Output Voltage: 24V DC
- Rated Power: 150W
- Current: 6.25A
- Efficiency: 90% at 277VAC; 87% at 120VAC
- Safety Certifications: UL, cUL, FCC, RoHS, CE
- Dimensions: 10" x 5.2" x 1.67"
- Weight: 4 lbs
FAQs
• What dimming methods are supported?
The driver supports TRIAC (forward-phase and reverse-phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming technologies.
• Can this driver be used outdoors?
Yes, its rugged NEMA 4X-rated metal housing is designed for reliable operation in wet, damp, and dry environments.
• What safety features does it include?
It features built-in protections against overload, short circuit, and over-temperature conditions for secure operation.
• What is the efficiency rating?
The driver operates at up to 90% efficiency at 277VAC and 87% at 120VAC, ensuring cost-effective performance.
