Malibu M5-120W-24V Multi-Channel 5-in-1 Dimmable Junction Box LED Driver

Malibu M5-120W-24V Multi-Channel 5-in-1 Dimmable Junction Box LED Driver

Regular price $195.00 USD
Regular price Sale price $195.00 USD
Sale Sold out

The Malibu M5-120W-24V is a high-performance Class 2 LED driver designed for 24V LED lighting systems. Engineered for professional and commercial applications, it delivers a constant 24V DC output at 5A (120W total) and supports advanced 5-in-1 dimming technologies. This driver is compatible with TRIAC (both forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimmers, ensuring smooth and flicker-free dimming for a wide range of lighting setups. Its robust design, housed in a NEMA 4X-rated metal enclosure, guarantees reliable operation in wet, damp, and dry environments. Certified to UL, cUL, FCC, and RoHS standards and backed by a 7-year warranty, the M5-120W-24V offers safety, durability, and long-term performance. For complete technical details, please refer to the spec sheet.

Key Features

  • Output Voltage & Power: 24V DC output delivering 5A and 120W total power.
  • 5-in-1 Dimming Technology: Supports TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming systems.
  • Flicker-Free Performance: Offers ultra-deep dimming—Voltage Reduce mode dims from 100% to 0.01%, while PWM mode dims from 100% to 0.1%.
  • High Efficiency: Operates at up to 90% efficiency at 277VAC, reducing energy usage.
  • Durable Construction: Rugged NEMA 4X-rated metal housing ensures reliable operation in wet, damp, and dry locations.
  • Advanced Safety Protections: Includes built-in overload, short circuit, and over-temperature (thermal) protections for secure operation.
  • Compact Design: Measures 10" x 5.2" x 1.67" and weighs 4 lbs, making installation easy.
  • Certified Quality: Compliant with UL, cUL, FCC, and RoHS standards.
  • Extended Warranty: Backed by a 7-year manufacturer warranty for long-term peace of mind.

Ideal Applications

  • LED linear and strip lighting
  • Residential and commercial lighting systems
  • Architectural and accent lighting

Specifications

  • Input Voltage Range: 110-277VAC
  • Output Voltage: 24V DC
  • Rated Power: 120W
  • Current: 5A
  • Efficiency: Up to 90% at 277VAC
  • Safety Certifications: UL, cUL, FCC, RoHS
  • Dimensions: 10" x 5.2" x 1.67"
  • Weight: 4 lbs

FAQs

What dimming methods are supported?
 This driver supports TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming.

Can this driver be used outdoors?
 Yes, the NEMA 4X-rated metal housing is designed for reliable operation in wet, damp, and dry environments.

What safety features does it include?
 It features built-in overload, short circuit, and over-temperature (thermal) protections for secure operation.

What is the efficiency rating?
 The driver operates at up to 90% efficiency at 277VAC, ensuring energy-efficient performance.
