Malibu Stardust™ M5-120W-12V 12V 120W Class 2 Multi-Channel 5-in-1 Dimmable Junction Box LED Driver
The Malibu M5-120W-12V is an efficient and versatile power supply engineered for 12V LED lighting systems. Designed for professional-grade applications, this Class 2 driver delivers a constant 12V DC output at 10A (120W total) and features advanced 5-in-1 dimming capabilities. It is compatible with TRIAC (both forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming systems—ensuring smooth, flicker-free dimming and precise lighting control.
Encased in a rugged NEMA 4X-rated metal housing, the driver is built for reliable operation in wet, damp, and dry environments. Certified to UL, cUL, FCC, and RoHS standards and backed by a 7-year warranty, the M5-120W-12V guarantees safe, long-term performance for residential, commercial, and architectural lighting projects. For complete technical details, please refer to the spec sheet.
Key Features
- Output Voltage & Power: 12V DC output delivering 10A and 120W total power.
- 5-in-1 Dimming Technology: Compatible with TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming systems.
-
Flicker-Free Performance:
- Voltage Reduce mode dims from 100% to 0.01%.
- PWM mode dims from 100% to 0.1%.
- High Efficiency: Achieves up to 90% efficiency at 277VAC, reducing energy consumption.
- Durable Construction: Rugged NEMA 4X-rated metal housing for reliable use in wet, damp, and dry environments.
- Advanced Safety Protections: Includes built-in safeguards against overload, short circuit, and over-temperature conditions.
- Compact Design: Measures 10" x 5.2" x 1.67" and weighs 4 lbs, facilitating easy installation.
- Certified Quality: Meets UL, cUL, FCC, and RoHS standards.
- Extended Warranty: Backed by a 7-year manufacturer warranty for peace of mind.
Ideal Applications
- LED tape and strip lighting
- Residential and commercial lighting systems
- Architectural and decorative lighting projects
Specifications
- Input Voltage Range: 110-277VAC
- Output Voltage: 12V DC
- Rated Power: 120W
- Current: 10A
- Efficiency: Up to 90% at 277VAC
- Safety Certifications: UL, cUL, FCC, RoHS
- Dimensions: 10" x 5.2" x 1.67"
- Weight: 4 lbs
FAQs
• What dimming methods are supported?
The driver supports TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming technologies.
• Can this driver be used outdoors?
Yes, its durable NEMA 4X-rated metal housing is designed for reliable operation in wet, damp, and dry environments.
• What safety features does it include?
It features built-in overload, short circuit, and over-temperature (thermal) protections for secure operation.
• What is the efficiency rating?
The driver operates at up to 90% efficiency at 277VAC, ensuring energy-efficient performance.
