Malibu Stardust™ M5-100W-24V 24V 100W Class 2 Multi-Channel 5-in-1 Dimmable LED Driver
The Malibu M5-100W-24V is a compact and reliable Class 2 LED driver designed for 24V LED lighting systems. Engineered for professional-grade applications, this driver delivers a constant 24V DC output at 100W (approximately 4.16A) while supporting advanced 5-in-1 dimming technologies. It is compatible with TRIAC (both forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming systems, ensuring smooth, flicker-free dimming and precise lighting control.
Built for durability, the driver is housed in a robust NEMA 4X-rated metal enclosure, making it suitable for wet, damp, and dry environments. Certified to UL, cUL, FCC, RoHS, and CE standards and backed by a 7-year manufacturer warranty, the M5-100W-24V offers safe, energy-efficient performance for residential, commercial, and architectural lighting projects. For complete technical details, please refer to the spec sheet.
Key Features
- Output Voltage & Power: 24V DC delivering 100W (approximately 4.16A)
- 5-in-1 Dimming Technology: Compatible with TRIAC (forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM
- Flicker-Free Performance: Ultra-deep dimming—Voltage Reduce mode from 100% to 0.01% and PWM mode from 100% to 0.1%
- High Efficiency: Up to 90% efficiency at 277VAC and 87% at 120VAC
- Durable Construction: Rugged NEMA 4X-rated metal housing for use in wet, damp, and dry environments
- Advanced Safety Protections: Includes safeguards for overload, short circuit, and thermal (over-temperature) conditions
- Compact & Lightweight: Measures 8.9" x 4.63" x 1.67" and weighs 2.2 lbs for easy installation
- Certified Quality: Meets UL, cUL, FCC, RoHS, and CE standards
- Extended Warranty: Backed by a 7-year manufacturer warranty
Ideal Applications
- LED linear and tape lighting
- Architectural and decorative lighting
- Residential and commercial lighting systems
FAQs
• What dimming methods are supported?
The driver supports TRIAC (both forward and reverse phase), 0-10V, 1-10V, Potentiometer, and 10V PWM dimming technologies.
• Can this driver be used outdoors?
Yes, its NEMA 4X-rated housing is designed for reliable operation in wet, damp, and dry environments.
• What safety features are included?
It includes built-in protections for short circuit, overload, and thermal (over-temperature) conditions.
• What is the efficiency rating?
The driver operates at up to 90% efficiency at 277VAC and 87% at 120VAC, ensuring cost-effective performance.
